How to Find the Height of a Hexagon
Determining the height of a hexagon is a common geometry problem that appears in school curricula, engineering design, and everyday tasks such as tiling or crafting. The height (also called the altitude or width depending on orientation) is the perpendicular distance between two parallel sides of the shape. For a regular hexagon—where all sides and interior angles are equal—this measurement can be derived directly from the side length using simple trigonometry. Irregular hexagons require a more general approach, often involving coordinate geometry or decomposition into triangles. Below is a step‑by‑step guide that explains the concepts, provides formulas, shows worked examples, and highlights practical tips to avoid common errors.
Understanding Hexagons
A hexagon is a six‑sided polygon. When all six sides are congruent and each interior angle measures 120°, the figure is a regular hexagon. If the sides or angles differ, the shape is irregular.
The height of a hexagon depends on how you orient the figure:
- Flat‑top orientation – two sides are horizontal; the height is the vertical distance between the top and bottom edges.
- Pointy‑top orientation – two vertices are aligned vertically; the height is the distance between the topmost and bottommost vertices.
In most textbook problems, the flat‑top orientation is assumed unless stated otherwise. The following sections focus on that case, but the same principles apply after rotating the shape 90°.
Height of a Regular Hexagon
Derivation of the Formula
Consider a regular hexagon with side length s. Draw a line from the center to the midpoint of one side; this line is the apothem (a). The apothem, the side length, and the radius of the circumscribed circle form a 30‑60‑90 right triangle:
- The central angle subtended by one side is 360°/6 = 60°.
- Half of that angle (the angle at the center in the right triangle) is 30°.
- The side opposite the 30° angle is s/2 (half the side length).
- The side adjacent to the 30° angle is the apothem a.
- The hypotenuse is the radius R of the circumscribed circle.
Using the properties of a 30‑60‑90 triangle (short leg : long leg : hypotenuse = 1 : √3 : 2):
[ \frac{s/2}{a} = \tan 30^\circ = \frac{1}{\sqrt{3}} \quad\Longrightarrow\quad a = \frac{s\sqrt{3}}{2} ]
The height h of the flat‑top hexagon is twice the apothem (distance from top side to bottom side through the center):
[ \boxed{h = 2a = s\sqrt{3}} ]
Thus, the height of a regular hexagon equals the side length multiplied by √3.
Quick Reference
| Quantity | Symbol | Formula |
|---|---|---|
| Side length | s | given |
| Apothem | a | (a = \frac{s\sqrt{3}}{2}) |
| Height (flat‑top) | h | (h = s\sqrt{3}) |
| Height (pointy‑top) | h′ | (h′ = 2s) (distance between opposite vertices) |
Step‑by‑Step Calculation for a Regular Hexagon
Follow these steps to find the height when you know the side length:
- Identify the side length (s). Ensure it is in the same unit you want the height expressed in (e.g., centimeters, inches).
- Multiply by √3. Use a calculator or the approximation √3 ≈ 1.7320508.
- Record the result with the appropriate unit.
Example 1
Problem: A regular hexagon tile has each side measuring 4 cm. What is its height?
Solution:
(h = s\sqrt{3} = 4 \times 1.73205 \approx 6.9282) cm.
Rounded to two decimal places, the height is 6.93 cm.
Example 2
Problem: A honeycomb cell (regular hexagon) has a height of 10 mm. Find the side length.
Solution:
Re‑arrange the formula: (s = \frac{h}{\sqrt{3}}).
(s = \frac{10}{1.73205} \approx 5.7735) mm.
Side length ≈ 5.77 mm.
Finding the Height of an Irregular Hexagon
When the hexagon is not regular, there is no single formula that depends only on one measurement. Instead, you must compute the perpendicular distance between two chosen parallel sides. Two common methods are:
Method A: Coordinate Geometry
If you can place the hexagon on a Cartesian plane (knowing the coordinates of its vertices), the height is simply the difference in the y‑coordinates of the two parallel sides (for flat‑top orientation) That alone is useful..
Steps:
- List the vertices in order (clockwise or counter‑clockwise).
- Identify the two sides you want to measure (e.g., the top and bottom edges).
- For each side, compute the y‑coordinate of its midpoint (or any point on the side, since the side is horizontal).
- Height = |y_top – y_bottom|.
Example: Vertices: (0,0), (5,0), (7,3), (5,6), (0,6), (-2,3).
Top side runs from (0,6) to (5,6) → y = 6.
Bottom side runs from (0,0) to (5,0) → y = 0.
Height = |6 – 0| = 6 units.
Method B: Decomposition into Triangles
Any polygon can be split into triangles whose areas are easier to compute. If you know the area (A) and the length of the base (b) of one of the parallel sides, the height follows from the area formula for a parallelogram:
[ \text{Area} = b \times h \quad\Longrightarrow\quad h = \frac{A}{b} ]
Steps:
- Choose one of the parallel sides as the base; measure its length b.
- Compute the total area of the hexagon (e.g., by dividing it into triangles and using Heron’s formula or the shoelace method).
